MicroNX ELEC AQUA 120K
ر.ق3,850.00
MicroNX ELEC AQUA 120K
Description
MicroNX ELEC AQUA 120K
Related products
MicroNX Elec Mini LED Mobile
Product Specifications
Please check the voltage and the electric power of the product, and conform to the instructions.
CONTROLLER
Dimension: W 113 x D 135 x H 45 mm
Speed control: Can be controlled through the button control method or foot pedal connection
MOTOR
Model: ELEC-LED
Motor: Brushless
Max.Speed: 40,000 rpm
Max.Torque: 3.0 N.cm
Dimension: L 72 x Ø 20 mm
Weight: 68 g
Optic: Yes
Internal water spray: Yes
MicroNX New ImplaNX Implant Motor
Product Specifications
Please check the voltage and the electric power of the product, and conform to the instructions.
ENGINE BODY
Power supply voltage: AC 110 ~ 240 V
Frequency: 50/60 Hz
Power consumption: 100 VA
Max. Coolant flow rate: 100 ml/min
Fuse: 2 x 250 V – T1.25 AH
Dimension: 250mm(W) x 250mm(L) x 110mm(H)
MOTOR
Model: ISM-B70L
Max. Speed: 40,000 rpm
Internal resistance(Phase to phase): 730 [mΩ]
Internal inductance(Phase to phase): 110 [uH]
Fuse: 24mm(Diameter) x 100mm(Length)
Weight: 80 g
Optic: Yes
FOOT PEDAL
Model: FC-V1
Speed control: Variable
Foot control functions: Program control, Coolant control, Forward/Reverse
ر.ق8,500.00Add to cart
